HIGH FREQUENCY GAPPED INDUCTOR

L/C Magnetics is a High Frequency inductor manufacturer. All our High Frequency Gapped Inductors are custom built to order. Current range is from 1 Amp to 300 Amps. Inductance values range from 1 uH to 50 mH. The core material can be Iron, Ferrite, or Metglas. The inductance is inversely proportional to the Gap of the inductor. Reducing the gap will increase the value of inductance.

Content is presented in two formats:  PHOTO FORMAT and TABLE FORMAT. The PHOTO FORMAT is shown first. The TABLE FORMAT is shown after the PHOTO FORMAT.

PHOTO FORMAT – HIGH FREQUENCY GAPPED INDUCTOR

High Frequency Gapped Inductor, 133 mH, 1 Amp, 100 Hz, P/N 18710L

High Frequency Gapped Inductor, 133 mH, 1 Amp, 100 Hz, P/N 18710L



High Frequency Gapped Inductor, 1.25 mH, 75 Amps, 415 Hz, P/N 18780L

High Frequency Gapped Inductor, 1.25 mH, 75 Amps, 415 Hz, P/N 18780L



High Frequency Power Inductor, 10 uH, 260 Amps, 377 to 423 Hz, P/N 18705L

High Frequency Power Inductor, 10 uH, 260 Amps, 377 to 423 Hz, P/N 18705L



High Frequency Power Inductor, 30 uH, 260 A, 377 to 423 Hz, P/N 18706L

High Frequency Power Inductor, 30 uH, 260 A, 377 to 423 Hz, P/N 18706L



Power Iron Core Inductor, 74 uH, 40 Amps, 4 kHz, P/N 18899L

Power Iron Core Inductor, 74 uH, 40 Amps, 4 kHz, P/N 18899L



High Frequency Gapped Inductor, 1 mH, 25 ADC, 10 kHz, P/N 18594L

High Frequency Gapped Inductor, 1 mH, 25 ADC, 10 kHz, P/N 18594L



Powder Iron Core Inductor, 10 uH, 250 ADC, 20 kHz, P/N 19030L

Powder Iron Core Inductor, 10 uH, 250 ADC, 20 kHz, P/N 19030L



High Frequency Gapped Inductor, 5 uH, 90 Amps, 377 to 423 Hz, P/N 18704L

High Frequency Gapped Inductor, 5 uH, 90 Amps, 377 to 423 Hz, P/N 18704L



High Frequency Gapped Inductor, 11 mH, 2 Amps, 3780 Hz, P/N 18735A

High Frequency Gapped Inductor, 11 mH, 2 Amps, 3780 Hz, P/N 18735A



Ferrite Core Gapped Inductor, 1 uH, 10 Amps RMS, 2 to 10 KHz, P/N 18595L

Ferrite Core Gapped Inductor, 1 uH, 10 Amps RMS, 2 to 10 KHz, P/N 18595L



Ferrite Core Gapped Inductor, 50 uH, 130 Amps, 10 KHz, P/N 18752L

Ferrite Core Gapped Inductor, 50 uH, 130 Amps, 10 KHz, P/N 18752L



Ferrite Core Gapped Inductor, 35 mH, 50 Amps, 16 KHz, P/N 18675L

Ferrite Core Gapped Inductor, 35 mH, 50 Amps, 16 KHz, P/N 18675L



Ferrite Core Inductor, 1000 uH, 21 A, 10 kHz, P/N 18679L

Ferrite Core Inductor, 1000 uH, 21 A, 10 kHz, P/N 18679L



Couple Gapped Inductor, 50 uH, 10 Amps RMS, 20 KHz, P/N 19015L

Couple Gapped Inductor, 50 uH, 10 Amps RMS, 20 KHz, P/N 19015L



High Frequency Gapped Inductor, 1 mH, 18 Amps, 25 KHz, P/N 18816L

High Frequency Gapped Inductor, 1 mH, 18 Amps, 25 KHz, P/N 18816L



High Frequency Gap Inductor, 40 mH, 25 Amps, 16 KHz, P/N 18695LP

High Frequency Gap Inductor, 40 mH, 25 Amps, 16 KHz, P/N 18695LP



The table below can be viewed in ascending or descending order for all categories such as P/N, Inductance (uH), Continuous Current (Amps) and Frequency (KHz) Click the Part Number to view more details and additional tap information. Only one tap detail is shown in the table.

TABLE FORMAT – HIGH FREQUENCY GAPPED INDUCTORS

P/NInductance (uH) Continuous Current (Amps)Frequency (KHz)
18710L13300010.1
18780L1250750.415
18705102600.423
18706L302600.423
18899L74404
18594L10002510
19030L1025020
18704L5900.423
18735A1100023.78
18595L11010
18752L5013010
18675L350005016
18679L10002110
19015L501020
18816L10001825
18695LP400002516

All our high frequency inductors are custom built to order. To discuss your specific application, please call us toll free at (800) 595-7096, or send us an email at info@LCMAGNETICS.COM.
