DELTA-DELTA TRANSFORMERS

L/C Magnetics is a Delta-Delta transformer specialist. All our transformers are custom built to order. These transformers are three phase. The isolation between primary and secondary is tested at 3000 VAC Hi-pot.

Examples of the Delta-Delta transformers are shown below. Click the photos for details.

Call Now For a Free Quote

We specialize in custom designed products.

We do not specialize in "off the shelf" products.

(800) 595-7096

DELTA-DELTA TRANSFORMERS

DELTA-DELTA TRANSFORMER, 1.5 KVA, PRIMARY 480 VAC, SECONDARY 480 VAC, P/N 19244

DELTA-DELTA TRANSFORMER, 1.5 KVA, PRIMARY 480 VAC, SECONDARY 480 VAC, P/N 19244



DELTA-DELTA TRANSFORMER, 3 KVA, PRIMARY 230 VAC, SECONDARY 11.5 VAC, P/N 19139

DELTA-DELTA TRANSFORMER, 3 KVA, PRIMARY 230 VAC, SECONDARY 11.5 VAC, P/N 19139



DELTA-DELTA TRANSFORMER, 7 KVA, PRIMARY 240 VAC, SECONDARY 22 VAC, P/N 19140

DELTA-DELTA TRANSFORMER, 7 KVA, PRIMARY 240 VAC, SECONDARY 22 VAC, P/N 19140



OPEN DELTA TO OPEN DELTA TRANSFORMER, 7.5 KVA, P/N 7786L2

OPEN DELTA TO OPEN DELTA TRANSFORMER, 7.5 KVA, P/N 7786L2



DELTA-DELTA TRANSFORMER, 15 KVA, PRIMARY 460 VAC, SECONDARY 42.5 VAC, P/N 19090

DELTA-DELTA TRANSFORMER, 15 KVA, PRIMARY 460 VAC, SECONDARY 42.5 VAC, P/N 19090



DELTA-DELTA TRANSFORMER, 22.5 KVA, PRIMARY 440 VAC, SECONDARY 440 VAC, P/N 19228N

DELTA-DELTA TRANSFORMER, 22.5 KVA, PRIMARY 440 VAC, SECONDARY 440 VAC, P/N 19228N



DELTA-DELTA TRANSFORMER, 25 KVA, PRIMARY 440 VAC, SECONDARY 210 VAC, P/N 19112N

DELTA-DELTA TRANSFORMER, 25 KVA, PRIMARY 440 VAC, SECONDARY 210 VAC, P/N 19112N



DELTA-DELTA TRANSFORMER, 30 KVA, PRIMARY 480 VAC, SECONDARY 101 VAC, P/N 19116N

DELTA-DELTA TRANSFORMER, 30 KVA, PRIMARY 480 VAC, SECONDARY 101 VAC, P/N 19116N



DELTA-DELTA TRANSFORMER, 30 KVA, PRIMARY 410 VAC, SECONDARY 86 VAC, P/N 19091A

DELTA-DELTA TRANSFORMER, 30 KVA, PRIMARY 410 VAC, SECONDARY 86 VAC, P/N 19091A



DELTA-DELTA TRANSFORMER, 30 KVA, PRIMARY 460 VAC, SECONDARY 86 VAC, 3 PH, 60 HZ, P/N 19091

DELTA-DELTA TRANSFORMER, 30 KVA, PRIMARY 460 VAC, SECONDARY 86 VAC, 3 PH, 60 HZ, P/N 19091



Start your custom order today!

The table below can be viewed in ascending or descending order for all categories such as P/N, Input (VAC), Output (VAC), Output (Amps), KVA ot Type. Click the Part Number to view more details and additional tap information. Only one tap detail is shown in the table.

TABLE FORMAT – WYE-WYE TRANSFORMERS

P/NINPUT
(VAC)
OUTPUT
(VAC)
OUTPUT
(AMPS)
KVATYPE
192444804801.81.5Three Phase
1913923011.51503.0Three Phase
19140240221847.0Three Phase
1909046042.520415Three Phase
19228N4404403022.5Three Phase
19112N44021068.725Three Phase
19116N4801019930Three Phase
19091A4108620130Three Phase
190914608620130Three Phase

All our transformers are custom built to order. To discuss your specific application, please call us toll free at (888) 594-3216, or send us an email at info@LCMAGNETICS.COM.
