HIGH FREQUENCY TRANSFORMER

L/C Magnetics offers a unique capability for High Frequency Transformers. Core material can be iron core, ferrite core or Metglas core. We have the proper tooling and the winding equipments to manufacture these units with a fast turn around.

Call Now For a Free Quote

We specialize in custom designed products.

We do not specialize in "off the shelf" products.

Content is presented in two formats,  PHOTO FORMAT and TABLE FORMAT. The PHOTO FORMAT is shown first. The TABLE FORMAT is shown after the PHOTO FORMAT.

 PHOTO FORMAT – HIGH FREQUENCY TRANSFORMERS

Ferrite Core High Current Transformer, 1 KVA, 1 PH, Frequency 10 KHz, P/N 18811

Ferrite Core High Current Transformer, 1 KVA, 1 PH, Frequency 10 KHz, P/N 18811



Ferrite Core High Frequency Transformer, 1 KVA, 1 PH, Frequency 5 KHz to 25 KHz, P/N 18750

Ferrite Core High Frequency Transformer, 1 KVA, 1 PH, Frequency 5 KHz to 25 KHz, P/N 18750



Audio Transformer, 1 KVA, 1 PH, 20 Hz to 30 kHZ, P/N 19149

Audio Transformer, 1 KVA, 1 PH, 20 Hz to 30 kHZ, P/N 19149



Start your custom order today!

The table below can be viewed in ascending or descending order for all categories such as P/N, Input (VAC), Output (VAC), Output (Amps), KVA ot Type. Click the Part Number to view more details and additional tap information. Only one tap detail is shown in the table.

TABLE FORMAT – HIGH FREQUENCY TRANSFORMERS

P/NInput (VAC)Output (VAC)Output (Amps)KVAType
1881120052001Single Phase
187502602.64001Single Phase
1914913.851606.251Single Phase

L/C Magnetics is a manufacturer of high frequency transformers. To discuss your specific application, please call us toll free at (800) 595-7096, or send us an email at info@LCMAGNETICS.COM.
