HIGH VOLTAGE TRANSFORMERS

L/C Magnetics specializes in high voltage dry type power transformers. Most High Voltage Transformers are oil filled transformers. L/C Magnetics does not make oil filled transformers. Sometimes an oil filled transformer is not an option. Then a dry type high voltage transformer is the next best choice available.

High Voltage Transformers can be single phase, three phase or Scott T configuration.

High voltage transformers can be high voltage windings or high voltage isolation between windings or both.

L/C Magnetics can manufacture High Voltage Transformers up to 20 KV of winding voltage or 20 KV of isolation voltage.

Call Now For a Free Quote

We specialize in custom designed products.

We do not specialize in "off the shelf" products.

HIGH VOLTAGE TRANSFORMERS (LOW PRIMARY, HIGH SECONDARY)

Dry Type High Voltage Transformer 200 KVA, 3 PH Primary: 480 VAC, 240 Amps Secondary: 3750 VAC, 31 Amps Isolation: 5 KV P/N 18278

Dry Type High Voltage Transformer 200 KVA, 3 PH Primary: 480 VAC, 240 Amps Secondary: 3750 VAC, 31 Amps Isolation: 5 KV P/N 18278



Multi Tap High Voltage Transformer 0.6 KVA, 1 PH Primary: 210/220/230/240 VAC, 3.15 Amps Secondary 1: -14.9/0/14.9, 1 Amp Secondary 2: 3750 VAC, 0.15 Amp P/N 19074

Multi Tap High Voltage Transformer 0.6 KVA, 1 PH Primary: 210/220/230/240 VAC, 3.15 Amps Secondary 1: -14.9/0/14.9, 1 Amp Secondary 2: 3750 VAC, 0.15 Amp P/N 19074



HIGH VOLTAGE TRANSFORMERS (LOW PRIMARY, LOW SECONDARY, HIGH ISOLATION)

20 KV Isolation Transformer, 100 VA, 1 PH, 60 Hz, P/N 19124

20 KV Isolation Transformer, 100 VA, 1 PH, 60 Hz, P/N 19124



10 KV Isolation Transformer, 0.44 KVA, 1 PH, 60 Hz, P/N 19098A

10 KV Isolation Transformer, 0.44 KVA, 1 PH, 60 Hz, P/N 19098A



5 KV Isolation Transformer, 175 VA, 1 PH, 60 Hz, P/N 19214A

5 KV Isolation Transformer, 175 VA, 1 PH, 60 Hz, P/N 19214A



5 KV Isolation Transformer, 0.44 KVA, 1 PH, 60 Hz, P/N 19098

5 KV Isolation Transformer, 0.44 KVA, 1 PH, 60 Hz, P/N 19098



5 KV Isolation Transformer, 0.5 KVA, 1 PH, 60 Hz, P/N 19076

5 KV Isolation Transformer, 0.5 KVA, 1 PH, 60 Hz, P/N 19076



3 KV Isolation Transformer, 1.2 KVA, 1 PH, P/N 18593

3 KV Isolation Transformer, 1.2 KVA, 1 PH, P/N 18593



4 KV Isolation Transformer, 1.5 KVA, 1 PH, 60 Hz, P/N 19102

4 KV Isolation Transformer, 1.5 KVA, 1 PH, 60 Hz, P/N 19102



5 KV Isolation Transformer, 7.5 KVA, 1 PH, P/N 19036

5 KV Isolation Transformer, 7.5 KVA, 1 PH, P/N 19036



5 KV Isolation Transformer, 10 KVA, 3 PH, P/N 18553

5 KV Isolation Transformer, 10 KVA, 3 PH, P/N 18553



20 KV Isolation Transformer, 25 KVA, 3 PH, P/N 18523N

20 KV Isolation Transformer, 25 KVA, 3 PH, P/N 18523N



60 KV Isolation Transformer, 0.5 KVA, 1 PH, 50/60 Hz, P/N 18844

60 KV Isolation Transformer, 0.5 KVA, 1 PH, 50/60 Hz, P/N 18844



Start your custom order today!

The table below can be viewed in ascending or descending order for all categories such as P/N, Input (VAC), Output (VAC), Output (Amps), KVA ot Type. Click the Part Number to view more details and additional tap information. Only one tap detail is shown in the table.

TABLE FORMAT – HIGH VOLTAGE TRANSFORMERS

P/NInput (VAC)Output (VAC)Output (Amps)KVAType
18278480375031200Three Phase
1907424014.910.6Single Phase
19124260200000.0050.1Single Phase
19098A22022020.44Single Phase
19214A12050760.0350.175Single Phase
1909822022020.44Single Phase
190761201204.20.5Single Phase
18593120120101.2Single Phase
19102416012012.51.5Single Phase
19036208120317.5Single Phase
185532082082810Three Phase
18523N2082087025Three Phase
1884412024020.5Single Phase

All our transformers are custom built to order. To discuss your specific application, please call us toll free at (800) 595-7096, or send us an email at info@LCMAGNETICS.COM.
