SHIELDED TRANSFORMERS

L/C Magnetics is a Shielded Transformer specialist. All our Shielded Transformers are custom built to order. The isolation between primary and secondary is tested at 3000 VAC Hi-pot.

Examples of the shielded transformers are shown below. Click the photos for details.

Call Now For a Free Quote

We specialize in custom designed products.

We do not specialize in "off the shelf" products.

SINGLE PHASE SHIELDED TRANSFORMERS

SHIELDED TRANSFORMER, 0.5 KVA, P/N 19234S

SHIELDED TRANSFORMER, 0.5 KVA, P/N 19234S



SHIELDED TRANSFORMER, 1 KVA, P/N 19130

SHIELDED TRANSFORMER, 1 KVA, P/N 19130



SHIELDED TRANSFORMER, 14.4 KVA, P/N 19194N

SHIELDED TRANSFORMER, 14.4 KVA, P/N 19194N



SHIELDED TRANSFORMER, 20 KVA, P/N 19262N

SHIELDED TRANSFORMER, 20 KVA, P/N 19262N



THREE PHASE SHIELDED TRANSFORMERS

SHIELDED TRANSFORMER, 1.2 KVA, 400 HZ, P/N 19183

SHIELDED TRANSFORMER, 1.2 KVA, 400 HZ, P/N 19183



SHIELDED TRANSFORMER, 1.5 KVA, P/N 19244

SHIELDED TRANSFORMER, 1.5 KVA, P/N 19244



SHIELDED TRANSFORMER, 2 KVA, P/N 19314

SHIELDED TRANSFORMER, 2 KVA, P/N 19314



SHIELDED TRANSFORMER, 5 KVA, P/N 19315

SHIELDED TRANSFORMER, 5 KVA, P/N 19315



SHIELDED TRANSFORMER, 35 KVA, P/N 17275A

SHIELDED TRANSFORMER, 35 KVA, P/N 17275A



Start your custom order today!

The table below can be viewed in ascending or descending order for all categories such as P/N, Input (VAC), Output (VAC), Output (Amps), KVA ot Type. Click the Part Number to view more details and additional tap information. Only one tap detail is shown in the table.

TABLE FORMAT - SHIELDED TRANSFORMERS

P/NINPUT
(VAC)
OUTPUT
(VAC)
OUTPUT
(AMPS)
KVATYPE
19234S11515000.5Single Phase
191302402204.51Single Phase
19194N240120/2406014.4Single Phase
19262N120/240120/24083.320Single Phase
1918320011511.2Three Phase
192444804801.81.5Three Phase
1931423023052Three Phase
1931523023012.55Three Phase
17257A4158611235Three Phase

All our transformers are custom built to order. To discuss your specific application, please call us toll free at (888) 598-1657, or send us an email at info@LCMAGNETICS.COM.
